15mm Permanent Magnet Geared Motor Dc 5v Micro Stepper Gear Motor With Encoder
Product Description
15mm Permanent Magnet Geared Motor DC 5V Micro Stepper Gear Motor with Encoder
Main Features
- 12*10mm gearbox plus 15mm stepping motor
- Small size dc gear motor with low speed and big torque
- 12mm gear motor provide 0.05Nm torque and more reliable
- Suitable to small diameter, low noise and big torque application
- Reduction ratio: 3, 5, 10, 20, 30, 50, 60, 100, 150, 210, 250, 298, 380
Motor GM12-15BY Specifications
| Model | Parameter Set A | Parameter Set B |
|---|---|---|
| GM12-15BY-30 | Rated voltage: 5VDC | Resistance: 10Ω |
| No.of Phase: 2 | Holding Torque: 500g.cm | |
| Step Angle: 18° | current: 500mA | |
| Gear Ratio: 1/30 | Pull in Rate: 800pps | |
| GM12-15BY-50 | Rated voltage: 5VDC | Resistance: 10Ω |
| No.of Phase: 2 | Holding Torque: 700g.cm | |
| Step Angle: 18° | current: 500mA | |
| Gear Ratio: 1/50 | Pull in Rate: 850pps | |
| GM12-15BY-110 | Rated voltage: 5VDC | Resistance: 10Ω |
| No.of Phase: 2 | Holding Torque: 1050g.cm | |
| Step Angle: 18° | current: 500mA | |
| Gear Ratio: 1/110 | Pull in Rate: 850pps |
Product Application
Automatic door operators, automatic energy saving bath, electrical controlled valve, robots, grass cutter, electric curtain, camera, medical service, oxygen machine, etc.
Other Applications
Business Machines
- Vending Machines
- Printers
- ATM
- Copiers and Scanners
Camera and Optical
- Video
- Cameras
- Projectors
Lawn and Garden
- Lawn Mowers
- Snow Blowers
- Trimmers
- Leaf Blowers
Certifications
ISO9001, SGS, National high-tech enterprises, etc.
Factory Production
We have been specializing in micro motors, gear motors and their respective parts since 2000. Our products are widely used in entertainment systems, automobiles, home and industrial appliances and tools and many others. Our products are dependable and long-lasting, and backed by years of experience. We export 98% of our output worldwide. By leveraging our hard-won reputation for honesty, dependability and quality, we aim to continue as a pioneer in sales overseas by seeking global partners. If your company is an end-user of micro-motors, a distributor or an agent, we look forward to being able to work together with you in the near future.
Our Customers
NIKE, FLEXTRONICS, STANLEY, etc.
Packing & Delivery
Standard packing
Shipping Methods & Estimated Time
DHL3-5 working days
UPS5-7 working days
TNT5-7 working days
FedEx7-9 working days
EMS12-15 working days
China Post / Sea Shipping: Transit time depends on destination country.
Customer Feedback
"Excellent quality, better price, good service, and on time delivery."
Frequently Asked Questions
Q1: How to order?
A: Send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit → mass production → cargo ready → balance/delivery → further cooperation.
Q2: How about sample order?
A: Sample is available for you. Please contact us for details. Once we charge you sample fee, please rest assured, it will be refunded when you place a formal order.
Q3: Which shipping way is available?
A: DHL, UPS, FedEx, TNT, EMS, China Post, and Sea are available. Other shipping ways can also be arranged, please contact us if you need delivery by alternative methods.
Q4: How long is the delivery [producing] and shipping?
A: Delivery time depends on the quantity you order. Usually it takes 15-25 working days.
Q5: My package has missing products. What can I do?
A: Please contact our support team and we will confirm your order with the package contents. We apologize for any inconvenience.
Q6: How to confirm the payment?
A: We accept payment by T/T and PayPal. Other payment ways can also be accepted; please contact us before processing payment through other methods. A 30-50% deposit is available, and the remaining balance should be paid before shipping.
